All in two solar street light-HS Series



Integrated solar streetlights utilize solar energy as their primary power source. They are not restricted by the availability of city power and do not require cabling, thereby eliminating the issues associated with traditional streetlights that feature multiple lines and require complicated installation. By reducing construction costs and minimizing the impact on the environment, they offer a more sustainable and cost-effective solution for street lighting.


MPPT Technology

MPPT is an advanced charging mode called Maximum Power Point Tracking, which can boost energy utilization by 15-20% compared to the PWM controller.

Multi-Peak MPPT

The new solar controller uses multi-peak MPPT technology to track the maximum power point and improve solar panel conversion efficiency.

IPC 5.0 Technology

After a decade of experience, we have upgraded our highly precise IPC technology to version 5.0. This intelligent power control system can detect recent weather conditions and plan the discharge power accordingly to achieve more rainy days.

ICD Technology (Intelligent Charge and Discharge)

Our Grade A LiFePO4 battery boasts excellent safety performance. Our unique current equalization technology and dual protection system (software and hardware) help the battery maintain 90% of its capacity even after 2000 cycles. Its lifetime is four times longer than that of lead-acid batteries.

Dual Low-power Consumption

With the help of 4-pins plug technology, the transportation power consumption is less than 0.05mA. Also, the circuit protection technology ensures the sleep power consumption in long-term storage, which is at the uA level. This enables worry-free storage for up to two years.

ITC Technology (Intelligent Temperature Control)

The system has an automatic switch-off to protect the battery at high temperatures, and a heating function for low-temperature settings, which extends the system's lifespan.

3.2V MPPT Technology

The use of single-string 3.2V MPPT technology reduces the probability of battery issues by 75%, which effectively improves product stability and extends lifetime by over three times compared to multi-string 12V technology.

Mode Memory Management

The system has a memory storage function that allows for both one-time operations and permanent preservation of data.


Type RS-HS300 RS-HS400
LED LAMP Powe 100W 130W
Light effeciency 200lm/w
LED chip SMD3030/400pcs
Luminous flux 16000lm 20800|m
Beam angle 60°*140°
Lifespan 50000hr
IP Rating IP65
Working temperature -20°C~60°℃(Charge above 0℃)
Color temperature 6000-6500K
CRI Ra≥70
Working mode 100%-2hrs,70%-2hrs,30%-dawn
SOLAR PANEL Power 2*150 W 2*200W
Voltage 18V
Type Monocrystalline silicon
Efficiency 19%-22%
BATTERY Power 1536WH 1920WH
Lighting time 5-7days
Lithium battery LiFePO4
Number of Battery 2 2
INSTALLATION Top diameter 60mm
Height 8-12M 10-12M
Spacing 25-35M
