THEMIS Dark Sky Friendly Solar Post Top Light | 2800lm High-Efficacy Pedestrian Lighting

Share to:

THEMIS Dark Sky Friendly Solar Post Top Light | 2800lm High-Efficacy Pedestrian Lighting

Name: THEMIS Dark Sky Friendly Solar Post Top Light | 2800lm High-Efficacy Pedestrian Lighting
Brand: E-ABLE POWER
Rating: 5.0 (77 reviews)

[THEMIS SERIES: DARK SKY FRIENDLY SOLAR POST TOP LIGHT -- 190LM/W UGR <1%]

Dark sky friendly solar post top light with UGR <1% glare-free precision optics -- protects nocturnal wildlife from light pollution. 2,800 lumens at 190lm/W efficacy. 38W monocrystalline panel (>22.5% efficiency), 154Wh Grade A LiFePO4 battery (6,000+ cycles), MPPT controller (97% efficiency). 4-hour charge, up to 5-day rainy-day autonomy. Dual CCT options, >100,000-hour LED life. Fully programmable intensity profiles for municipal tenders. IP65 rated. CE, RoHS, Dark Sky Compliant. 5-year global warranty. Complimentary DIALux simulation included.

Availability:

Quantity:



Inquire Add to Basket

Model:
THEMIS Series
Brand:
E-ABLE POWER
Code:
Themis

Product Description

E-ABLE POWER — PRODUCT DATASHEET

ARCHITECTURAL SOLAR LIGHTING SOLUTIONS

DARK SKY CERTIFIED 190LM/W UGR<1%

THEMIS Series | Dark Sky Friendly Solar Post Top Light

THEMIS Series Dark Sky Friendly Solar Post Top Light

An ecologically engineered solar post top light with UGR<1% glare-free opticsdesigned to protect nocturnal wildlife from light pollution. Delivers 2,800 lumens at 190lm/W efficacy with a 38W monocrystalline panel, 154Wh Grade A LiFePO4 battery, and MPPT controller. Dual CCT options, 6,000+ cycles, up to 5 days of rainy-day autonomy. Ideal for eco-resorts, municipal parks, wildlife corridors, and dark sky communities.

✉ Request Project Quote ☎ WhatsApp +86 153-5558-9600

Key Specifications at a Glance

• Model: THEMIS Series — Dark Sky Post Top Light• Max Luminous Flux: 2,800 lm — UGR<1% Glare-Free• Luminous Efficacy: 190 lm/W — Industrial Class• Solar Panel: 38W Monocrystalline Silicon (>22.5% Eff.)• Battery: 154Wh Grade A LiFePO4 — 6,000+ Cycles• Charging Time: 4 Hours Direct Sunlight• Rainy-Day Autonomy: Up to 5 Days (MPPT)• LED Lifetime: >100,000 Hours — Dual CCT Options• Control: MPPT Solar Engine — Programmable Profiles• Certifications: CE / RoHS / Dark Sky Compliant• Warranty: 5 Years Global

THEMIS Series ecological solar post top light — dark sky friendly design with UGR less than 1 percent glare-free optics

Ecological Innovation Meets High Efficacy

THEMIS prioritizes UGR<1% precision opticsto eliminate harsh glare and harmful blue-light impact on nocturnal wildlife. Managed by an intelligent MPPT solar engine with 97% conversion efficiency, it provides environmentally respectful 2,800-lumen path lighting while preserving natural darkness — fully programmable light intensity and duration profiles for municipal tender requirements.

THEMIS Series advanced solar system architecture infographic — MPPT controller, LiFePO4 battery, monocrystalline panel, and glare-free LED optics

Technical Specifications

Parameter	Specification
Lighting Performance
Max Luminous Flux	2,800 lm — Dark Sky Friendly Precision Optics
Luminous Efficacy	190 lm/W — Industrial Class Efficiency
Glare Rating (UGR)	<1%— Essentially Glare-Free, Nocturnal Wildlife Safe
CCT Options / LED Lifetime	Dual CCT Configurable / >100,000 Hours (L70)
Energy & Storage System
Solar PV Power	38W Monocrystalline Silicon — >22.5% Conversion Efficiency
Battery Pack	154Wh Grade A LiFePO4 — 6,000+ Cycles
Charge Controller	MPPT — 97% Conversion Efficiency — Programmable Profiles
Charging Time	4 Hours — Standard Direct Sunlight
Rainy-Day Autonomy	Up to 5 Days — MPPT Adaptive Power Management
Certifications	CE / RoHS / Dark Sky Compliant
Warranty	5 Years Global

Table 1.0 — THEMIS Series technical specifications. UGR<1% verified optics for dark sky compliance. MPPT-controlled charging for up to 5-day autonomy. Dual CCT configurable at order. Custom light intensity and duration profiles available for municipal tender specifications.

Frequently Asked Questions

Q: What does UGR<1% mean for my project and how is it achieved?

Unified Glare Rating (UGR) measures discomfort glare on a scale from 5 (unnoticeable) to 40+ (painful). A rating of <1% is essentially glare-free— pedestrians perceive the illuminated area without ever seeing a bright light source. THEMIS achieves this through a precision-engineered optical lens array that directs all light downward within a controlled cutoff angle, eliminating upward light spill and horizontal glare. For municipalities and eco-resorts, this means: (1) compliance with dark sky ordinances in sensitive areas, (2) zero impact on nocturnal wildlife navigation and breeding patterns, and (3) more comfortable pedestrian experience without the harsh "glare halo" common on standard post-top luminaires.

Q: How does THEMIS achieve 5 days of autonomy with a 154Wh battery?

Three factors combine for extended autonomy: (1) 190lm/W system efficacy — THEMIS produces the same 2,800 lumens while consuming significantly less energy than standard 100-130lm/W post-top lights, (2) MPPT charge controller with 97% conversion efficiency — extracts nearly all available energy from the 38W panel vs typical 85-90% for PWM controllers, and (3) programmable intensity profiles — the system can be configured to reduce brightness during low-traffic hours (e.g., 100% dusk-10pm, 50% 10pm-dawn), extending runtime to 5+ nights from a single full charge. This is critical for regions with extended rainy seasons where 2-3 overcast days are common.

Q: Can THEMIS be customized for municipal tender specifications?

Yes. THEMIS features a fully programmable MPPT controller supporting custom light intensity schedules and duration profiles per municipal requirements. Configurable parameters include: dimming curve (any combination of brightness levels across the night), CCT selection (dual CCT options for amber/warm corridors vs standard pathways), adaptive brightness based on battery state-of-charge, and motion sensor triggering (optional). E-Able Power provides complimentary DIALux lighting simulation with iso-lux maps and pole layout for tender submission documentation. Contact engineering with your tender specification — complete technical proposal within 2-3 business days.

Q: Where is THEMIS most commonly deployed, and what maintenance is required?

THEMIS is purpose-built for dark sky communities, eco-resorts, national parks, coastal boardwalks, wildlife corridors, and municipal pedestrian pathways where light pollution regulations and wildlife protection are project requirements. The fixture is fully self-contained — no trenching, no cabling, no grid connection. Maintenance: annual cleaning of the solar panel surface (glass cleaner + soft cloth), visual inspection of the optical lens for debris, and BMS SoH check. The LiFePO4 battery requires no water, no electrolyte, and no equalization — rated for 6,000+ cycles (10+ years nightly operation). IP65-rated housing protects against rain, dust, and humidity. The LED array is rated >100,000 hours (L70) — exceeding 25 years in nightly use. 5-year global warranty.

Quality Assurance & Certifications

ISO
9001

Quality Mgmt

ISO
14001

Environmental

CE

EU Compliance

RoHS

Hazard-Free

DARK
SKY

UGR<1%

Factory: Dongguan, Guangdong, China. CE / RoHS certified. Dark Sky compliant — UGR<1% verified. 5-year global warranty.
