ZC-TYD2505 Architectural Solar Post Top Light

Name: ZC-TYD2505 Architectural Solar Post Top Light
Brand: E-ABLE POWER
Rating: 5.0 (56 reviews)

[ZC-TYD2505: ARCHITECTURAL SOLAR POST TOP LIGHT -- 45W / 60,000MAH / 200 LED]

Die-cast aluminum fixture, IP65 waterproof. 5V/45W monocrystalline solar panel, 3.2V/60,000mAh (192Wh) Grade A LiFePO4 battery, 200 high-efficacy LED array in cylindrical 360-degree configuration. 580x580x255mm, powder-coated finish. Mounts on 76mm posts at 4-6m (post by installer). 3000K warm white (4000K optional). 3-5h charge, 8-12h nightly, 2-3 nights autonomy. 2,000+ cycles (10+ years). Zero trenching, zero cabling, zero grid connection. CE, RoHS. 5-year warranty. OEM for 50+ units.

Availability:

Quantity:



Inquire Add to Basket

Model:
ZC-TYD2505
Brand:
E-ABLE POWER
Code:
ZC-TYD2505

Product Description

E-ABLE POWER — PRODUCT DATASHEET

ARCHITECTURAL SOLAR LIGHTING SOLUTIONS

ARCHITECTURAL SERIES 45W / 200 LED / IP65

ZC-TYD2505 | Architectural Solar Post Top Light

ZC-TYD2505 Architectural Solar Post Top Light

A premium architectural solar post top light crafted from heavy-duty die-casting aluminum with IP65 waterproof rating. Integrates a 5V/45W monocrystalline solar panel, massive 60,000mAh LiFePO4 battery, and 200 high-efficacy LED array into a symmetrical lantern-style enclosure. Delivers uniform 360-degree ambient illumination without dark spots — ideal for upscale residential communities, public parks, pathways, and commercial plazas. Zero grid connection, zero trenching, zero electricity cost.

✉ Request Project Quote ☎ WhatsApp +86 153-5558-9600

Key Specifications at a Glance

• Model: ZC-TYD2505 — Architectural Post Top Light• Housing: Heavy-Duty Die-Casting Aluminum• Solar Panel: 5V / 45W Monocrystalline Silicon• Battery: 3.2V / 60,000mAh (192Wh) Grade A LiFePO4• Charging Time: 3-5 Hours Direct Sunlight• LED Array: 200 PCS High-Efficacy LED Chips• Light Distribution: 360-Degree Uniform Ambient Glow• CCT: 3000K Warm White (4000K Optional)• IP Rating: IP65 — Waterproof & Weather-Resistant• Dimensions: 580×580×255mm• Mounting Height: 4-6 Meters (76mm Post Diameter)• Certifications: CE / RoHS• Warranty: 5 Years Standard

Core Engineering Advantages

High-Density 200 LED Array

200 high-efficacy LED chips arranged in a cylindrical configuration deliver uniform 360-degree ambient output with zero dark spots — 3-6x the LED count of conventional post-top lights for visibly superior illumination quality.

Massive 60,000mAh Power Reserve

192Wh of Grade A LiFePO4 storage — the largest battery in the decorative post-top class. 3-5h solar charge supports multi-night autonomy, ensuring consistent nightly operation even after consecutive overcast days.

Architectural Durability

Die-casting aluminum housing with powder-coated finish + IP65 sealed enclosure — corrosion-resistant structural integrity for year-round outdoor operation. Symmetrical lantern design complements upscale landscape aesthetics.

ZC-TYD2505 architectural solar post top light — symmetrical design, technical dimensions and product layout diagram

Fig 1.0: Symmetrical Design & Technical Layout — Die-Cast Aluminum Housing

Technical Specifications

Parameter	Specification
General Specifications
Model Number	ZC-TYD2505
Housing Material	Heavy-Duty Die-Casting Aluminum — Powder-Coated Finish
Protection Rating	IP65 — Waterproof / Weather-Resistant / Dustproof
Power & Battery System
Solar PV Power	5V / 45W Monocrystalline Silicon — High-Efficiency Panel
Battery Technology	3.2V / 60,000mAh (192 Wh) — Grade A LiFePO4
Charging Time	3-5 Hours — Standard Direct Sunlight
Battery Cycle Life	2,000+ Deep Cycles — 10+ Years in Nightly Operation
Lighting & Physical Dimensions
LED Quantity	200 PCS High-Efficacy LED Array — 360° Cylindrical Configuration
Color Temperature	3000K Warm White (Standard) / 4000K Neutral White (Optional)
Fixture Dimensions	580 × 580 × 255 mm (H)
Recommended Mounting Height	4,000mm - 6,000mm (4-6 Meters) — 76mm Post Diameter
Certifications	CE / RoHS

Table 1.0 — ZC-TYD2505 technical specifications. Post not included — mounts on standard 76mm diameter post (provided by installer). CCT selectable at order. 5-year standard warranty. OEM branding available for orders above 50 units.

Ideal Landscape Applications

Pedestrian Pathways Upscale Residential Communities Public Parks & Gardens Commercial Plazas Hotel & Resort Grounds Campus Walkways

Frequently Asked Questions

Q: How long does the ZC-TYD2505 illuminate per night on a full charge?

With the 60,000mAh (192Wh) LiFePO4 battery fully charged (3-5 hours direct sunlight), the ZC-TYD2505 provides 8-12 hours of continuous illumination at full brightness — covering a full night in any season. In sensor/dimming mode, runtime extends to 2-3 nights of autonomous operation. The massive battery reserve (4-6x larger than typical decorative post-top lights) means the fixture maintains reliable nightly illumination even after 2-3 consecutive overcast days — eliminating the "dark light" problem common on undersized-battery solar luminaires.

Q: What post types is the ZC-TYD2505 compatible with?

The ZC-TYD2505 is designed for standard 76mm (3-inch) diameter posts — compatible with most commercial post-top mounting systems. The fixture mounts via a top-cap adapter (included) that secures to the post crown. Post material can be aluminum, steel, or concrete — the fixture's own weight (die-cast aluminum construction) is compatible with all standard post structural ratings at the 4-6m recommended height. Note: the post itself is not included — provided by the installer or supplied separately by E-Able Power upon request. Solar panel must have direct sun exposure — avoid mounting under dense tree canopy.

Q: How does the 200-LED array compare to standard post-top lights?

The ZC-TYD2505's 200-LED cylindrical array is a significant differentiator from conventional solar post-top lights, which typically use 30-60 LEDs in a single-directional or limited-arc configuration. The high-density, full-circle arrangement achieves three key advantages: (1) True 360-degree uniform output — no directional dark spots common on single-panel LED configurations, (2) Lower individual LED drive current — each of the 200 LEDs operates below its maximum rating, reducing thermal stress and extending LED lifespan beyond 50,000 hours, and (3) Superior visual quality — the high LED count creates a smooth, continuous glow rather than visible individual point sources, complementing architectural landscape aesthetics.

Q: What installation and maintenance does the ZC-TYD2505 require?

Installation: mount the top-cap adapter on a 76mm post (4-6m height) in a location with direct sun exposure on the top panel. No underground cabling, no electrical permit, no grid connection — the fixture is fully self-contained. Maintenance: annual cleaning of the solar panel surface (glass cleaner + soft cloth) to maintain optimal charging efficiency. The LiFePO4 battery requires no water, no electrolyte, and no equalization — rated for 2,000+ cycles (10+ years). The IP65-sealed die-cast aluminum housing has no gaskets to replace. LED array is not user-serviceable but rated for 50,000+ hours — exceeding 15 years in nightly operation. 5-year standard warranty covers manufacturing defects.

Quality Assurance & Certifications

ISO
9001

Quality Mgmt

ISO
14001

Environmental

CE

EU Compliance

RoHS

Hazard-Free

IP65

Waterproof

Factory: Dongguan, Guangdong, China. CE / RoHS certified. 5-year standard warranty. OEM branding available for orders above 50 units.
