View Product E-ABLE POWER — PRODUCT DATASHEET
COMMERCIAL SOLAR LIGHTING SOLUTIONS
DUAL-PROFILE SERIES 8,000MAH / 5W
Key Specifications at a Glance
| Models | ZC-CPD1106-1 / ZC-CPD1106-2 | Profile | Rectangular — 235 × 140mm |
| Solar Panel | 5V / 5W Monocrystalline | Battery | 3.2V / 8,000mAh Grade A LiFePO4 |
| LED Array | 30 PCS High-Efficacy LED Chips | CCT | 3000K – 6500K Selectable |
| Charging Time | 3 – 5 Hours Direct Sunlight | Heights | 600mm / 800mm Options |
| Housing | Die-Casting Aluminum + PC | IP Rating | IP65 — Waterproof & Weather-Resistant |
| Certifications | CE / RoHS | Warranty | 5 Years Standard |
Fig 1.0: ZC-CPD1106 Series — Rectangular Dual-Profile Solar Bollard (CPD1106-1 & CPD1106-2 Variants)
Engineering Excellence
Distinctive Rectangular Profile
A unique 235×140mm rectangular cross-section — a deliberate departure from cylindrical bollard conventions. The flat faces provide superior directional light distribution and a modern architectural silhouette that complements contemporary landscape design. Two cosmetic variants (CPD1106-1 / CPD1106-2) offer subtle design differentiation for cohesive multi-zone projects.
Highest Panel Wattage in Class
The 5V/5W monocrystalline panel delivers the highest solar input in E-Able's bollard range — 25% more than the 4.5W class. Combined with the 8,000mAh LiFePO4 battery, it ensures faster charge recovery and deeper energy reserves. 3-5h full charge provides 10-12 hours of consistent illumination with multi-night autonomy during overcast periods.
Dual-Height Design Flexibility
Available in 600mm and 800mm heights — deploy 600mm units along secondary pathways and garden borders, and 800mm units at main promenades and entry plazas. The rectangular form factor creates clean sightlines when aligned in rows, and the two variant designs allow visual rhythm variation within a single installation.
Technical Specifications
| Specification | ZC-CPD1106-1 / ZC-CPD1106-2 |
|---|---|
| Housing Material | Die-Casting Aluminum + Impact-Resistant PC |
| Profile Shape | Rectangular — 235 × 140mm Cross-Section |
| Height Options | 600mm / 800mm — Two Configurations Available |
| Solar Panel | 5V / 5W — High-Efficiency Monocrystalline Silicon |
| Battery Capacity | 3.2V / 8,000mAh (25.6Wh) — Grade A LiFePO4 |
| LED Configuration | 30 PCS High-Efficacy LED Chips |
| Color Temperature | 3000K – 6500K (Selectable CCT) |
| Charging Time | 3 – 5 Hours — Standard Direct Sunlight |
| Design Variants | CPD1106-1 (Variant A) / CPD1106-2 (Variant B) — Same Core Specifications |
| IP Rating | IP65 — Waterproof / Weather-Resistant |
| Installation | Surface-Mount / Stake-Down — Zero Trenching, Zero Wiring |
| Certifications | CE / RoHS |
Table 1.0 — ZC-CPD1106-1 and ZC-CPD1106-2 share identical electronics, materials, and performance. CPD1106-1 vs CPD1106-2 differ in cosmetic design detailing only. Both available in 600mm and 800mm heights. Mix variant and height combinations for visually dynamic landscape compositions. 5-year standard warranty.
Ideal Landscape Applications
Corporate Campuses Upscale Residential Borders Commercial Promenades Luxury Hotel Pathways
Frequently Asked Questions
Q: What sets the ZC-CPD1106 apart from cylindrical bollards — why choose rectangular?
The 235×140mm rectangular profile offers three distinct advantages over cylindrical bollards. Directional light control: flat faces project illumination forward and to the sides with less upward spill, creating cleaner pathway wash. Architectural alignment: the rectilinear form integrates naturally with modern building facades, straight pathways, and structured landscape geometry. Visual variety: in multi-zone projects, mixing rectangular CPD1106 bollards with cylindrical models from the CPD4104 or CPD0907 series creates deliberate design contrast. The two cosmetic variants (CPD1106-1 and CPD1106-2) add subtle design differentiation — alternate them along a single pathway for a rhythmic visual cadence without compromising lighting uniformity.
Q: How does the 5W panel benefit performance compared to lower-wattage bollards?
The 5V/5W monocrystalline panel is the highest in E-Able's bollard range — 25% more input power than 4W-class bollards and 150% more than entry-level 2W models. This means faster charge recovery after overcast days — the battery reaches full capacity in fewer sun hours. Paired with the 8,000mAh LiFePO4 battery, the 5W panel supports 10-12 hours of full-brightness nightly operation with reliable multi-night autonomy during extended bad weather. The higher panel wattage is particularly valuable in higher-latitude regions with shorter winter daylight hours, where lower-wattage bollards may struggle to fully recharge. For projects in northern Europe, Canada, or similar latitudes, the CPD1106's 5W panel provides a meaningful operational margin.
Q: How do I use CPD1106-1 and CPD1106-2 together in one project?
The two variants share identical core specifications — same electronics, materials, and lighting performance. They differ only in cosmetic design detailing (housing trim, light aperture pattern, or top cap styling). Recommended deployment strategy: alternate CPD1106-1 and CPD1106-2 along a single pathway (e.g., CPD1106-1 at every even position, CPD1106-2 at every odd position) for a subtle, sophisticated visual rhythm; or assign each variant to a different zone — CPD1106-1 along the main promenade, CPD1106-2 along secondary garden paths — for intuitive wayfinding differentiation. Combine with both 600mm and 800mm heights for maximum compositional flexibility: tall CPD1106-1 at entry plazas, mid CPD1106-2 along connecting paths, creating a cohesive yet varied landscape lighting system from a single product family.
Q: What maintenance and warranty coverage does the CPD1106 include?
Annual maintenance is minimal — clean the solar panel surface (glass cleaner + soft cloth) to maintain optimal charging, and visually inspect the die-cast aluminum housing for any impact damage. The IP65-sealed construction protects all internal electronics from rain, dust, and environmental corrosion — no gasket replacement, no repainting, no anti-rust treatment required. The Grade A LiFePO4 battery provides 2,000+ deep-discharge cycles (5-7 years of nightly operation) and is user-replaceable without specialized tools, extending total fixture life beyond 15 years. 5-year standard warranty covers manufacturing defects. For large-scale deployments, E-Able Power provides complimentary DIALux lighting simulation and complete technical documentation within 2-3 business days.
E-Able Power is an ISO 9001 & ISO 14001 certified manufacturer. All ZC-CPD1106 bollards are CE and RoHS compliant with 5-year standard warranty.
