ZC-GGD4505 Classic European Multi-Head Solar Post Light

Name: ZC-GGD4505 Classic European Multi-Head Solar Post Light
Brand: E-ABLE POWER
Rating: 5.0 (77 reviews)

[ZC-GGD4505: CLASSIC EUROPEAN MULTI-HEAD SOLAR POST LIGHT -- DOUBLE & TRIPLE HEAD CONFIGURATIONS]

Two heritage-styled models at 2.6m tall: ZC-GGD4505-2 (Double Head, 800mm dia, 5V/9W panel, 3.2V/16,000mAh battery, 60 LED) and ZC-GGD4505-3 (Triple Head, 750mm dia, 5V/13.5W panel, 3.2V/24,000mAh battery, 90 LED). Die-casting aluminum + impact-resistant PC housing, IP65 waterproof. Independent light engines per head for wide-area glare-free illumination. 3-5h charge, dusk-to-dawn optical sensor. For historical old towns, outdoor cafe plazas, park promenades, and residential entrances. CE. 5-year warranty. OEM for 50+ units.

Availability:

Quantity:



Inquire Add to Basket

Model:
ZC-GGD4505-2 / ZC-GGD4505-3
Brand:
E-ABLE POWER
Code:
ZC-GGD4505

Product Description

E-ABLE POWER — PRODUCT DATASHEET

HERITAGE SOLAR LIGHTING SOLUTIONS

CLASSIC EUROPEAN 2.6M / IP65

ZC-GGD4505 | Classic European Multi-Head Solar Post Light

ZC-GGD4505 Classic European Multi-Head Solar Post Light

A heritage-styled solar lantern system that brings classic European street-light aesthetics to off-grid solar technology. Two configurations: ZC-GGD4505-2 (Double Head, 800mm dia, 9W/16,000mAh/60LED) for balanced ambient illumination, and ZC-GGD4505-3 (Triple Head, 750mm dia, 13.5W/24,000mAh/90LED) for higher-output wide-area coverage. Standing at a commanding 2.6 meters tall, each fixture features independent LED engines per head, die-casting aluminum + impact-resistant PC housing, IP65 weatherproofing, and intelligent dusk-to-dawn optical sensor. Designed for historical old towns, outdoor cafe plazas, park promenades, and upscale residential entrances — where architectural character and lighting performance carry equal weight. Zero trenching, zero cabling, zero grid connection.

✉ Request Project Quote ☎ WhatsApp +86 153-5558-9600

Key Specifications at a Glance

• Models: ZC-GGD4505-2 (Double) / ZC-GGD4505-3 (Triple)• Style: Classic European Lantern — Heritage Aesthetic• Height: 2,600 mm — Full Integrated Post Fixture• Solar Panel: 5V 9W (Double) / 5V 13.5W (Triple) Monocrystalline• Battery: 3.2V 16,000mAh (51Wh) / 24,000mAh (77Wh) Grade A LiFePO4• LED: 60 PCS (Double) / 90 PCS (Triple) — Independent Light Engines• Charging: 3-5 Hours Direct Sunlight• Control: Smart Dusk-to-Dawn Optical Sensor• GGD4505-2 Dims: Φ800 × H2,600mm• GGD4505-3 Dims: Φ750 × H2,600mm• IP Rating: IP65 — Waterproof / Weatherproof• Certifications: CE• Warranty: 5 Years Standard

ZC-GGD4505 classic European multi-head solar post light — die-casting aluminum heritage lantern with independent LED engines, 2.6m tall, IP65, for historical districts and outdoor plazas

Fig 1.0: ZC-GGD4505 Series — Double Head (Left) and Triple Head (Right) Heritage Solar Lanterns, 2.6m Tall

Engineering Excellence

Independent Multi-Head LED Engines

Each head houses a dedicated LED array with its own diffuser — 60 LEDs across 2 heads (GGD4505-2) or 90 LEDs across 3 heads (GGD4505-3). This independent architecture creates overlapping light cones that eliminate dark zones and shadows typical of single-source fixtures, delivering wide-area ambient illumination ideal for broad boulevards, promenades, and plaza perimeters.

Heritage Die-Cast Aluminum Build

The 2.6-meter integrated post and lantern housing are die-casting aluminum — the same durable manufacturing process used in premium European-style gas and electric street lamps, now adapted for solar. The impact-resistant PC diffusers on each head provide shatter-resistant light distribution with UV-stabilized clarity. IP65 sealed against rain, dust, and environmental corrosion — ensuring the classic aesthetic endures without the maintenance burden of traditional heritage fixtures.

Proportional Power Scaling

Power systems scale precisely with head count. GGD4505-2 (Double): 9W panel feeds a 16,000mAh (51Wh) battery powering 60 LEDs across 2 heads. GGD4505-3 (Triple): 13.5W panel feeds a 24,000mAh (77Wh) battery powering 90 LEDs across 3 heads. Both achieve 3-5 hour full recharge and 8-10 hours of continuous dusk-to-dawn operation. Grade A LiFePO4 chemistry — 2,000+ cycles, thermal stability >270 deg C, zero cobalt, zero maintenance. The proportional scaling ensures neither model is battery-constrained or over-paneled.

Model Comparison & Technical Specifications

Specification	ZC-GGD4505-2 (Double Head)	ZC-GGD4505-3 (Triple Head)
Design Style	Classic European Heritage Lantern
Fixture Height	2,600 mm — Integrated Post Fixture (Self-Standing)
Head Configuration	2 Heads — Symmetrical Pair	3 Heads — 120° Radial Array
Fixture Diameter	Φ800 mm	Φ750 mm
Housing Material	Die-Casting Aluminum + Impact-Resistant PC Diffusers
Solar Panel (Mono)	5V / 9W	5V / 13.5W
Battery (LiFePO4)	3.2V / 16,000mAh (51 Wh)	3.2V / 24,000mAh (77 Wh)
LED Quantity	60 PCS (2 × 30 per Head)	90 PCS (3 × 30 per Head)
Charging Time	3-5 Hours — Standard Direct Sunlight
Control System	Smart Optical Sensor — Automated Dusk-to-Dawn Operation
Protection Rating	IP65 — Waterproof / Dustproof / Weather-Resistant
Battery Cycle Life	2,000+ Cycles at 80% DOD — 8+ Years Operational
Certifications	CE

Table 1.0 — ZC-GGD4505-2 vs ZC-GGD4505-3 comparison. Both models: integrated 2.6m post fixture, die-casting aluminum + impact-resistant PC construction, IP65 rated, smart dusk-to-dawn sensor. GGD4505-3 recommended for high-visibility heritage plazas and wide boulevards with its triple-head 24,000mAh/90LED system. GGD4505-2 ideal for promenades and residential entries with balanced double-head output. 5-year standard warranty.

Ideal Heritage & Hospitality Applications

Historical Old Towns & Districts Outdoor Cafe & Restaurant Plazas Park Promenades & Boardwalks Upscale Residential Entrances Boutique Hotel & Resort Grounds

Frequently Asked Questions

Q: What makes the ZC-GGD4505 suitable for historical and heritage districts?

Three design elements align with heritage district requirements. Architectural authenticity: the classic European lantern profile with multi-head configuration replicates the visual language of traditional gas and early-electric street lamps — critical for conservation-area approvals where modern minimalist fixtures would be rejected. Zero-ground-disturbance installation: as a fully self-contained solar fixture, the GGD4505 requires no trenching, no underground cabling, and no grid connection — preserving archaeological layers, mature tree roots, and historic paving that would be destroyed by conventional wired lighting infrastructure. Warm CCT compatibility: the 3000K warm-white option (within the 3000-6500K selectable range) matches the amber glow of traditional gas lamps, maintaining the intended nighttime character of heritage streetscapes.

Q: How should I choose between the double-head and triple-head configurations?

Select by spatial context and illumination demand. ZC-GGD4505-2 (Double Head, 800mm dia, 9W/16,000mAh/60LED): symmetrical paired heads project light along a linear axis — ideal for pathways, promenades, and walkways where the primary illuminated zone runs parallel to the fixture row. The wider 800mm profile creates a strong architectural presence. ZC-GGD4505-3 (Triple Head, 750mm dia, 13.5W/24,000mAh/90LED): three heads at 120-degree radial spacing project light in all directions — ideal for plazas, squares, and open gathering areas where 360-degree coverage is needed. The higher battery capacity (24,000mAh vs 16,000mAh) supports the 50% greater LED count without compromising runtime. Mix both in a single project: triple-head units at plaza centers and intersections, double-head units along connecting pathways.

Q: How does the 2.6-meter integrated post design affect installation and stability?

The ZC-GGD4505 is a complete integrated fixture — post, lantern body, solar panel, battery, and LED engines are factory-assembled into a single unit. This is fundamentally different from post-top fixtures that mount onto a separate pole. Installation: the integrated base plate bolts to a concrete foundation pad or embedded anchor bolts (foundation by installer per local code). No separate post procurement, no post-to-fixture adapter compatibility issues. At 2.6 meters, the fixture complies with standard pedestrian-scale lighting height guidelines while providing sufficient elevation for the solar panel to receive unobstructed sunlight. The die-casting aluminum post body provides inherent structural rigidity and corrosion resistance at all connection points — there is no steel-to-aluminum galvanic corrosion risk. Foundation bolt pattern and load specifications provided in the technical datasheet.

Q: What ongoing maintenance does the GGD4505 require?

The ZC-GGD4505 is engineered for minimal intervention — a key advantage for heritage districts where maintenance vehicle access may be restricted and scaffolding around historic structures is undesirable. Annual maintenance: clean the solar panel surface and PC diffusers with glass cleaner + soft cloth to maintain optimal charging and light transmission. The dusk-to-dawn optical sensor requires no seasonal adjustment. Battery replacement: the Grade A LiFePO4 battery (2,000+ cycles) reaches 80% capacity at approximately year 7-8 of nightly operation. The battery compartment is accessible via a service hatch in the post body — no disassembly of the lantern head required. A scheduled battery swap extends total fixture service life beyond 15 years. No water, no electrolyte, no equalization, no painting, no rust treatment. 5-year standard warranty covering the complete fixture.

Quality Assurance & Certifications

ISO
9001

Quality Mgmt

ISO
14001

Environmental

EU Compliance

IP65

Waterproof

5 YR

Warranty

Factory: Dongguan, Guangdong, China. CE certified. ISO 9001 quality management + ISO 14001 environmental management. Integrated 2.6m die-casting aluminum post + lantern body. IP65 rated. Grade A LiFePO4 battery — zero cobalt, thermal stability >270 deg C. 5-year standard warranty.
