ZC-TYD Series Urban V-Arm Solar Post Top Light (TYD2705 & TYD2403)

Name: ZC-TYD Series Urban V-Arm Solar Post Top Light (TYD2705 & TYD2403)
Brand: E-ABLE POWER
Rating: 5.0 (98 reviews)

[ZC-TYD SERIES: URBAN V-ARM SOLAR POST TOP LIGHT -- 20W / 80LED / 20,000MAH]

Two architectural forms with a distinctive V-shaped support canopy: ZC-TYD2705 (Round, 480xH410mm) and ZC-TYD2403 (Square, 400x400xH420mm). Die-casting aluminum + high-impact PC housing, IP65 waterproof. 5V/20W high-efficiency monocrystalline panel, 3.2V/20,000mAh (64Wh) Grade A LiFePO4 battery, 80 SMD LED array with 3000-6500K CCT. 3-5h charge. Dusk-to-dawn optical sensor. Zero trenching, zero grid connection. For city plazas, commercial pedestrian zones, corporate campuses, and public transit hubs. CE. 5-year warranty. OEM for 50+ units.

Availability:

Quantity:



Inquire Add to Basket

Model:
ZC-TYD Series (ZC-TYD2705 / ZC-TYD2403)
Brand:
E-ABLE POWER
Code:
ZC-TYD-SERIES

Product Description

E-ABLE POWER — PRODUCT DATASHEET

MUNICIPAL SOLAR LIGHTING SOLUTIONS

MUNICIPAL GRADE V-ARM DESIGN / IP65

ZC-TYD Series | Urban V-Arm Solar Post Top Light

ZC-TYD Series Urban V-Arm Solar Post Top Light

Two architectural forms united by the distinctive V-shaped support canopy — a signature design element that elevates urban solar lighting beyond pure utility. ZC-TYD2705 (Round, 480xH410mm) for soft-radius integration into landscaped plazas; ZC-TYD2403 (Square, 400x400xH420mm) for crisp geometric alignment with modern architecture. Both models share: 5V/20W monocrystalline panel, 3.2V/20,000mAh (64Wh) Grade A LiFePO4 battery, 80 SMD LED array with 3000-6500K selectable CCT, IP65 die-casting aluminum + high-impact PC housing, and integrated dusk-to-dawn optical sensor. Zero trenching, zero cabling, zero grid connection — designed for city plazas, commercial pedestrian zones, corporate campuses, and public transit hubs.

✉ Request Project Quote ☎ WhatsApp +86 153-5558-9600

Key Specifications at a Glance

• Models: ZC-TYD2705 (Round) / ZC-TYD2403 (Square)• Design: Distinctive V-Arm Support Canopy• Solar Panel: 5V / 20W Monocrystalline• Battery: 3.2V / 20,000mAh (64Wh) Grade A LiFePO4• LED Array: 80 SMD Chips — 3000-6500K Selectable CCT• Charging Time: 3-5 Hours Direct Sunlight• Housing: Die-Casting Aluminum + High-Impact PC• TYD2705 Dims: Φ480 × H410mm• TYD2403 Dims: 400 × 400 × H420mm• IP Rating: IP65 — Waterproof / Dustproof• Certifications: CE• Warranty: 5 Years Standard

ZC-TYD Series V-arm urban solar post top lights — TYD2705 Round canopy vs TYD2403 Square canopy, die-casting aluminum + PC, IP65, for city plazas and commercial pedestrian zones

Fig 1.0: ZC-TYD Series — Round TYD2705 vs Square TYD2403, Distinctive V-Arm Canopy Design

Core Engineering Advantages

Signature V-Arm Architecture

The distinctive V-shaped support canopy is both an aesthetic statement and a functional optimization — the angled arms channel rainwater away from the solar panel surface and LED housing, reducing dust accumulation and maintaining charging efficiency. This design language identifies the ZC-TYD Series as premium municipal-grade infrastructure, not commodity lighting. Available in round (TYD2705) and square (TYD2403) canopy profiles to match urban architectural context.

IP65 Dual-Material Housing

Die-casting aluminum frame for structural rigidity and passive heat dissipation + high-impact PC diffuser for lightweight durability and UV-stable light transmission. The IP65 seal protects internal electronics against heavy rain, dust ingress, and environmental corrosion — tested for year-round outdoor deployment in municipal and transit environments.

Balanced 80 LED + 20,000mAh System

Precisely matched energy budget: 80 SMD LEDs with 3000-6500K selectable CCT provide glare-controlled ambient illumination without harsh hotspots, while the 20,000mAh (64Wh) LiFePO4 battery sustains 8-10 hours of continuous dusk-to-dawn operation. The 20W monocrystalline panel achieves full recharge in 3-5 hours — optimized for the moderate solar resource of mid-latitude cities.

Model Comparison & Technical Specifications

Specification	ZC-TYD2705 (Round)	ZC-TYD2403 (Square)
Canopy Profile	Round (Circular)	Square (Rectilinear)
Fixture Dimensions	Φ480 × H410 mm	400 × 400 × H420 mm
Solar Panel	5V / 20W — High-Efficiency Monocrystalline
Battery	3.2V / 20,000mAh (64 Wh) — Grade A LiFePO4
LED Array	80 PCS High-Lumen SMD — 3000K ~ 6500K Selectable CCT
Charging Time	3-5 Hours — Standard Direct Sunlight
Control System	Intelligent Optical Sensor — Automated Dusk-to-Dawn
Housing Material	Die-Casting Aluminum Frame + High-Impact PC Diffuser
Protection Rating	IP65 — Waterproof / Dustproof / Weather-Resistant
Battery Cycle Life	2,000+ Cycles at 80% DOD — 8+ Years Operational
Certifications	CE

Table 1.0 — ZC-TYD2705 vs ZC-TYD2403 comparison. Both models share identical electronics: 20W monocrystalline panel, 20,000mAh Grade A LiFePO4 battery, 80 SMD LED array with 3000-6500K selectable CCT, optical dusk-to-dawn sensor, and IP65-rated die-casting aluminum + PC housing. Choose by architectural canopy preference — round for softer landscape integration, square for crisp modern geometry. Mix both within a single project. 5-year standard warranty.

Target Municipal Applications

City Plazas & Squares Commercial Pedestrian Zones Corporate Campuses Public Transit Hubs University & Hospital Grounds

Frequently Asked Questions

Q: What is the functional purpose of the V-arm canopy design?

The V-shaped support arms serve both aesthetic and practical functions. Structurally, the angled arms channel rainwater away from the solar panel surface and LED housing, reducing dust and water-spot accumulation that would otherwise degrade charging efficiency. The open-frame design also improves passive airflow around the solar panel, keeping it cooler during peak sunlight hours — cooler panels generate more power. Aesthetically, the V-arm silhouette creates a recognizable architectural identity that signals premium municipal-grade infrastructure, distinguishing these fixtures from generic commodity post-top lights. The V-arm geometry is consistent across both round (TYD2705) and square (TYD2403) canopy profiles.

Q: How should I choose between the round TYD2705 and square TYD2403?

The two models are electronically identical — same 20W panel, 20,000mAh battery, 80 LED array, and IP65 rating. The decision is purely architectural. ZC-TYD2705 (Round, 480mm dia): softer visual profile that integrates naturally into landscaped environments, curved pathways, and organic park layouts. ZC-TYD2403 (Square, 400x400mm): crisp rectilinear geometry that aligns with modern building facades, grid-pattern plazas, and structured urban hardscape. The models can be mixed within a single project — use round canopies along winding paths and square canopies in formal courtyard zones, all sharing identical light output, color temperature, and maintenance procedures.

Q: What is the expected battery lifespan and replacement procedure?

The Grade A LiFePO4 battery is rated for 2,000+ deep cycles at 80% DOD — equivalent to 5-7 years of nightly dusk-to-dawn operation in typical municipal deployment before reaching 80% of original capacity. Key advantages: thermal stability >270 deg C (no thermal runaway risk), zero cobalt (ethical supply chain), and zero maintenance (no water, no electrolyte, no equalization). The battery is user-replaceable via the housing access panel — a scheduled swap at year 7-8 extends total fixture service life beyond 15 years with only one battery replacement. For municipal tenders, E-Able Power can include spare battery packs in the initial procurement to lock in today's pricing for future swaps.

Q: What installation requirements and cost advantages does the ZC-TYD Series offer?

Each fixture is fully self-contained: solar panel, battery, LED array, and optical sensor are integrated into a single housing — no separate components to coordinate. Installation requires no trenching, no underground cabling, no grid connection, and no electrical permit. Mount on standard post top at appropriate height (post by installer, not included). Each unit installs in under 30 minutes. The immediate cost advantages for municipal projects are substantial: eliminate trenching and conduit costs (typically 40-60% of conventional lighting project budgets), zero ongoing electricity bills, and zero grid-infrastructure maintenance. Annual maintenance: clean the solar panel and PC diffuser with glass cleaner + soft cloth. 5-year standard warranty. E-Able Power provides complimentary DIALux simulation for tender-stage lighting design.

Quality Assurance & Certifications

ISO
9001

Quality Mgmt

ISO
14001

Environmental

CE

EU Compliance

IP65

Waterproof

5 YR

Warranty

Factory: Dongguan, Guangdong, China. CE certified. ISO 9001 quality management + ISO 14001 environmental management. IP65 die-casting aluminum + PC housing. Grade A LiFePO4 battery — zero cobalt, thermal stability >270 deg C. 5-year standard warranty.

Related Solar Lighting Products

ZC-TYD2505 200 LED / 60,000mAh Post Top

ZC-TYD2806 / GGD0805 160 LED / 45,000mAh Dual Design

ZC-TYD2403 25W / 20,000mAh Garden Light

Request DIALux Free lighting simulation

Illuminate Your Urban Landscape with ZC-TYD Series

Round or square — one V-arm design, two architectural forms. Contact E-Able Power for wholesale pricing, complimentary DIALux simulation, and complete municipal tender documentation. Technical proposal within 2-3 business days.
